Convex

Finish

Painted aluminum and metal. Inner diffusor in opal acrylic. Outer in transparent acrylic.

LED info

System power 6W. Luminaire Luminous Flux 370LM. CCT 3000K. SDCM 3. CRI >90. L80 B10 50.000H.

Installation

For standard foundations 108 mm or above ground with accessory 93415-1-xx.

Connection

Terminal block 5x10mm2.

Classification

IK 10, IP 44.

Design

Jens Fager 2016.

Standard colours

Other colours on request.

Product sheet

Designer

Project


				Product specification
				Now Convex has evolved into both a pole fixture and a bollard. It has the same amiable expression with the slightly curved top, where the design’s clarity and the construction’s durability contribute to a long life. Energy efficient due to its LED technology. IK 10.

					W
				D/H/MM
				COLOUR
				ART.

					LED 370LM/6W
					133/1039
					Black
					3415-1-06

					LED 370LM/6W
					133/1039
					Corten
					3415-1-47

					LED 370LM/6W
					133/1039
					Galvanized
					3415-1-83

					Accessories

					Ground base for installation above ground
					300x300
					Black
					93415-1-06

					Ground base for installation above ground
					300x300
					corten
					93415-1-47

					Ground base for installation above ground
					300x300
					Galv
					93415-1-83

Product specification Now Convex has evolved into both a pole fixture and a bollard. It has the same amiable expression with the slightly curved top, where the design’s clarity and the construction’s durability contribute to a long life. Energy efficient due to its LED technology. IK 10.
W	D/H/MM	COLOUR	ART.
LED 370LM/6W	133/1039	Black	3415-1-06
LED 370LM/6W	133/1039	Corten	3415-1-47
LED 370LM/6W	133/1039	Galvanized	3415-1-83
Accessories
Ground base for installation above ground	300x300	Black	93415-1-06
Ground base for installation above ground	300x300	corten	93415-1-47
Ground base for installation above ground	300x300	Galv	93415-1-83
