Convex

Finish

Painted or galvanized steel. DIffuser in matt tempered glass.

LED info

System power 9W. Luminaire Luminous Flux 505LM. CCT 3000K. SDCM 3. CRI>80.

Installation

Surface mounted wall installation.

Connection

Terminal block 3x4mm2. When HFF 5x4mm2.

Classification

IP 20 or IP 44.

Design

Jens Fager 2014.

Standard colours

Other colours on request.

Product sheet

Designer


				Product specification

					W
				FINISH
				IP
				ART.

					LED 505LM/9W
					White
					IP44
					8290-1-01

					LED 505LM/9W
					White
					IP20
					8290-1-01HFF

					LED 505LM/9W
					Black
					IP44
					8290-1-06

					LED 505LM/9W
					Black
					IP20
					8290-1-06HFF

					LED 505LM/9W
					Galvanized
					IP44
					8290-1-83

					LED 505LM/9W
					Galvanized
					IP20
					8290-1-83HFF

					GU10/max35W
					White
					IP44
					8292-1-01

					GU10/max35W
					Black
					IP44
					8292-1-06

					GU10/max35W
					Galvanized
					IP44
					8292-1-83

					HFF = Dimmbart drivdon DALI, DSI alt SwitchDim.

Product specification
W	FINISH	IP	ART.
LED 505LM/9W	White	IP44	8290-1-01
LED 505LM/9W	White	IP20	8290-1-01HFF
LED 505LM/9W	Black	IP44	8290-1-06
LED 505LM/9W	Black	IP20	8290-1-06HFF
LED 505LM/9W	Galvanized	IP44	8290-1-83
LED 505LM/9W	Galvanized	IP20	8290-1-83HFF
GU10/max35W	White	IP44	8292-1-01
GU10/max35W	Black	IP44	8292-1-06
GU10/max35W	Galvanized	IP44	8292-1-83
HFF = Dimmbart drivdon DALI, DSI alt SwitchDim.
